Description
Description
62.5° approach for 7° positive 55° rhombic inserts.
-
- • Set Type Individual Toolholder
- • Cutting Direction Neutral
- • ISO Designation SDNCN 1212F07
- • Clearance Angle 7°
- • Insert Inscribed Circle 6.35mm
SDNCN 1010E07 EXTERNAL TO OLHOLDER
-
Set TypeIndividual Toolholder
-
Cutting DirectionNeutral
-
ISO DesignationSDNCN 1212F07
-
Clearance Angle7°
-
Insert Inscribed Circle6.35mm
-
Insert Shape55 Rhombic
-
Head Length (l2)16mm
-
Cutting Height (h1)12mm
-
Shank Height (h)10mm
-
Insert StyleDC_T
-
Neck Length16mm
-
Insert Size0702
-
Shank Width (b)10mm
-
Insert Holding TypeScrew -On
-
Shank StyleStraight
-
Approach Angle62.5°
-
Toolholder StyleSDNC
-
Shank MaterialSteel
-
Inserts IncludedNone
-
Product NumberSDNCN1010E07
-
Insert Cutting Edge Length7mm
-
Coolant DeliveryExternal
-
Side to Cutting Tip (f)5mm
-
Overall Length (l1)70mm
