Description
Description
90° approach for 7° positive triangular inserts.
- • Neck Length (l2) 40mm
- • Insert Cutting Edge Length 16.5mm
- • Set Type Individual Boring Bar
S25T STFCR 16 BORING BAR
-
Neck Length (l2)40mm
-
Insert StylemmTC_Tmm
-
Insert Cutting Edge Length16.5mm
-
Set TypeIndividual Boring Bar
-
Insert ShapeTriangle
-
Insert Inscribed Circle9.52mm
-
Shank MaterialSteel
-
Coolant DeliveryExternal
-
Minimum Bore Diameter (D)31mm
-
Approach Angle90°
-
Inserts IncludedNone
-
Clearance Angle7°
-
Cutting Height (h1)11.5mm
-
Product Number0
-
Number of Bars in SetN/A
-
Toolholder StyleSTFC
-
ISO DesignationS25T STFCR 16
-
Centre to Cutting Tip17mm
-
Insert Holding TypeScrew-On
-
Cutting DirectionRight Hand
-
Overall Length (l1)300mm
-
Shank Diameter (d)25mm
-
Shank Height (h)23mm
-
Insert Sizemm16T3mm
