Sherwood Sherwood.SET OF 19 HSS DRILLS 1-10.00mm x 0.5mm – SHR0258460K

Sherwood Sherwood.SET OF 19 HSS DRILLS 1-10.00mm x 0.5mm – SHR0258460K

Sherwood.SET OF 32 HSS DRILLS 1-10.50mm x 0.5mm - SHR0258470KSherwood.4-30mm SHEET METAL STEP DRILLS HSS (SET-3) - SHR0190260K

Add to Wishlist
Compare
Category:
Brand:

Description

Description

Sherwood Jobber drills are general purpose drills for steels, cast steel, grey cast iron, malleable cast iron, nickel brass, aluminium alloy and graphite. Industrial quality. Ground flute, blue finish. Supplied in indexing metal cases. Point angle: 118, helix angle: normal, web thickness: standard, relief angle: 10-20, tolerance of diameter: h8, tolerance of shank: f11. Manufactured to BS328 : Part 1 DIN 338N & ANSI B94 – 11M. Set contains: 1.0, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0, 6.5, 7.0, 7.5, 8.0, 8.5, 9.0, 9.5 and 10.0mm.

    • • Case Type Metal Case
    • • Flute Construction Ground Flute
    • • Finish/Coating Black Oxide
    • • Drill Size Included 1mm to 10mm x 0.5mm
    • • System of Measurement Metric

SET OF 19 HSS DRILLS 1-10.00mm x 0.5mm

  • Case Type

    Metal Case
  • Flute Construction

    Ground Flute
  • Finish/Coating

    Black Oxide
  • Drill Size Included

    1mm to 10mm x 0.5mm
  • System of Measurement

    Metric
  • Maximum Drill Size

    10mm
  • Drill Length Type

    Standard Length
  • Size Increment

    0.5mm
  • Number of Pieces

    19
  • Standards Met

    ANSI B94-11M
    BS 328
    DIN 338N
  • Cutting Direction

    Right Hand
  • Minimum Drill Size

    1mm
  • Material

    High Speed Steel
