CCMT Turning Inserts 80° Rhombic Insert Insert Grade QX5030 (ISO P20-P40 M20-M30) CVD Coated. – Medium / rough turning and intermediate cutting of steel / stainless steel. Combination of toughest substrate and alumina coating (MT-TiCN + TiC + AL2O3 + TiN) having superior chipping resistance provide wide coverage. Chip Breaker: PM. Application: Med Cut.
-
- • Manufacturer Grade QX5030
- • Inscribed Circle 9.525mm
- • Insert Style CCMT
- • Corner Radius 0.4
- • Cutting Edge Length 9mm
CCMT 09T304-PM INSERT GRADE QX5030
-
Manufacturer Grade
QX5030 -
Inscribed Circle
9.525mm -
Insert Style
CCMT -
Corner Radius
0.4 -
Cutting Edge Length
9mm -
Thickness
3.97mm -
Cutting Direction
Neutral -
Finish/Coating
Tin-MT-TiCN-Al2O3-TiN -
Shape
80° Rhombic -
Material Application
Stainless SteelSteel -
ISO Cut
M20 to M30P20 to P40 -
Insert Size
09T3 -
Material
Carbide -
Chipbreaker
PM -
ISO Designation
CCMT 09T304-PM -
ISO Category Grade
MP -
Clearance Angle
7°
