Description
The Full Stainless Steel hose reels are perfect for a variety of different applications, from the food industry to the boating industry and the chemical sector, heavy duty work environments with corrosive atmosphere. They are the ideal for industrial cleaning, blowing operations and transport of fluids such as air, water, oil, diesel and AdBlue.
Even more fluids
 |
Air |
 |
High pressure water |
 |
Hot water |
 |
Oil |
 |
Diesel |
 |
AdBlue |
TECHNICAL DATA
- Brackets in Stainless Steel AISI 304
- Screws and bolts in Stainless Steel AISI 316L
- End pipe fitting and incomig fitting in Stainless Steel AISI 316L
- Coil shaft, bushings, ring nuts and rotating shaft in Stainless Steel AISI 304
- Automatic blocking device for the hose at the required length
- Reel roller hose guide that can be moved in different configurations to help the reeling of the hose.
- Adjustable hose stopper
| Art. |
Hose int. Ø (mm)
|
Hose (m)
|
Hose type
|
Incoming fitting
|
End pipe fitting
|
Max press
(bar) |
Use
|
|
|---|---|---|---|---|---|---|---|---|
| 8401/1113 | without hose | 1/2″ F | 1/2″ F | 20 | AIR WATER | |||
| 8404/1111 | 10 (3/8″) |
12 | SAE 100R6 | 1/2″ F | 3/8″ M | 20 | AIR WATER | |
| 8406/1111 | 10 (3/8″) |
18 | SAE 100R6 | 1/2″ F | 3/8″ M | 20 | AIR WATER | |
| 8426/1111 | 12,5 (1/2″) |
15 | KPU | 1/2″ F | 1/2″ M | 20 | AIR WATER | |
| 8427/1111 | 12,5 (1/2″) |
20 | KPU | 1/2″ F | 1/2″ M | 20 | AIR WATER | |
| 8432/1111 | 12,5 (1/2″) |
12 | PU – FOOD QUALITY* | 1/2″ F | 1/2″ M | 15 | WATER | |
| 8482/1111 | 19 (3/4″) |
8 | PVC – PU | 3/4″ M | 3/4″ F | 15 | AD BLUE | |
| 8440/1113 | without hose | 3/8″ F | 1/2″ F | 200 | OIL WATER | |||
| 8442/1111 | 10 (3/8″) |
15 | EN857 1 SC Black | 3/8″ F | 3/8″ F | 200 | OIL WATER | |
| 8443/1111 | 10 (3/8″) |
18 | EN857 1 SC Black | 3/8″ F | 3/8″ F | 200 | OIL WATER | |
| 8446/1111 | 10 (3/8″) |
15 | EN857 1 SC Blue | 3/8″ F | 3/8″ F | 200 | OIL WATER | |
| 8448/1111 | 10 (3/8″) |
18 | EN857 1 SC Blue | 3/8″ F | 3/8″ F | 200 | OIL WATER |
