Description
TECHNICAL DATA
- Technopolymer casing
- Complete with pivot bracket
- Provided with hose ratchet stop device, easily removable if constant traction is required
- KPU hose
| Art. |
Hose int. Ø (mm)
|
Hose (m)
|
Incoming fitting
|
End pipe fitting
|
Max press
(bar) |
Use
|
|
|---|---|---|---|---|---|---|---|
| 804/8 | 8 (5/16″) |
10 | NO | 1/4″ M | 15 | AIR WATER | |
| 804/8/S | 8 (5/16″) |
10 | NO | 1/4″ M | 15 | AIR WATER | |
| 804/10 | 10 (3/8″) |
8 | NO | 3/8″ M | 15 | AIR WATER | |
| 804/10/S | 10 (3/8″) |
8 | NO | 3/8″ M | 15 | AIR WATER | |
| 805/8 | 8 (5/16″) |
16 | NO | 1/4″ M | 15 | AIR WATER | |
| 805/8/S | 8 (5/16″) |
16 | NO | 1/4″ M | 15 | AIR WATER | |
| 805/10 | 10 (3/8″) |
16 | NO | 3/8″ M | 15 | AIR WATER | |
| 805/10/S | 10 (3/8″) |
16 | NO | 3/8″ M | 15 | AIR WATER | |
| 805/13 | 12.5 (1/2″) |
11 | NO | 1/2″ M | 15 | AIR WATER | |
| 805/13/S | 12.5 (1/2″) |
11 | NO | 1/2″ M | 15 | AIR WATER |
