Description
Description
Capacity : 1000 kg
Load centre distance : 500 mm
Wheelbase : 1290 mm
Height, mast lowered : 1885 mm
Max. Lift height : 3000 mm
Height, mast extended : 3570 mm
Overall length : 2185 mm
Overall width : 950 mm / 1200 mm
Fork dimension : 40 mm x 100 mm x 950 mm
Reach distance : 500 mm
Turning radius : 1750 mm
Travel speed : 4.5 km / 5 h
Lift speed : 0,095 m / 0,12 s
Lowering speed : 0,2 m / 0,15 s
Lift motor : 3 kW
Battery voltage : 24 V / 320 Ah
Service weight : 1385 kg
